Material
ULTEM 9085

ULTEM 9085

Engineering Plastics
Heat resistantChemical resistantFunctionalFlame retardant

ULTEM 9085 is a flame-retardant high-performance thermoplastic for digital manufacturing and rapid prototyping. It is ideal for the transportation industry due to its high strength-to-weight ratio and its FST (flame, smoke, and toxicity) rating. ULTEM 9085 allows design and manufacturing engineers to produce fully functional parts that are ideal for advanced functional prototypes or end-use parts without the cost or lead time of traditional tooling. It has a lower resistance to chemicals but is highly retardant to flames (UL94 V-0 compliant).

Print with ULTEM 9085
Mechanical Properties
Tensile strength69–86 MPa
Tensile modulus2150–2230 MPa
Elongation4.5–6 %
Flexural strength90–116 MPa
Flexural modulus2126–2500 MPa
Density1.34 g/cm³
Thermal
Heat deflection at 66 PSI158–175 °C
Print Constraints

Maximum build volume

914 × 610 × 914 mm

Default layer height0.2 mm
Default infill20%
Min embossing0.8 mm
Min engraving0.8 mm
Accuracy± 0.3 mm
Warping riskOver_140_mm
Interlocking partsNot supported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

Standard

3 colors

Standard layered finish.

Sanded

Sanded

3 colors

Smooth sanded finish.
