SLS Nylon PA6

Nylons

FunctionalImpact resistantDurableHeat resistant

Nylon (polyamide PA) is a fantastic all-round material with high precision and a good value for money. Thanks to its strength and flexibility it is extremely versatile and suitable for functional parts, jewelry, and many more applications. When thin, it is flexible enough for springs – when thick, it is strong enough for functional parts. It comes in many colors, and its surface can be polished and dyed. This material is 3D printed on industrial grade 3D printers, offering the highest quality, using a process called Selective Laser Sintering. PA6 is stronger than PA12, but absorbs more water.

Print with SLS Nylon PA6

Mechanical Properties

Tensile strength66–74 MPa

Tensile modulus3457–3700 MPa

Elongation2–4 %

Flexural strength90–100 MPa

Flexural modulus2842–3350 MPa

Density1.15 g/cm³

Thermal

Heat deflection at 66 PSI189–192 °C

Heat deflection at 264 PSI93–103 °C

Print Constraints

Maximum build volume

450 × 450 × 450 mm

Default layer height0.1 mm

Default infill100%

Min embossing0.7 mm

Min engraving0.7 mm

Accuracy± 0.3 mm

Warping riskOver_140_mm

Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Mineral Filled

1 color

Anthracite mineralfilled SLS Nylon featuring a slighly coarse matte surface and increased strength.

Standard

2 colors

Raw SLS nylon PA6 featuring a coarse surface.
