Print
Material
PCTG

PCTG

Standard Plastics
FunctionalChemical resistantStrongWater resistant

PCTG (Poly Cyclohexylenedimethylene Terephthalate Glycol) belongs to the same copolyester family as PETG, but it uses a higher concentration of the same glycol modifier, which gives it meaningfully better impact resistance. This is why parts are less likely to shatter under sudden stress compared to standard PETG. The raw tensile and flexural strength are similar to PETG; the real improvement is in toughness, not baseline strength. PCTG also absorbs less moisture, which helps it retain its clarity and mechanical properties for longer in humid conditions, and it offers good chemical resistance along with excellent optical clarity. Like PETG, it isn't optimized for long-term outdoor UV exposure – ASA remains the better option in that case scenario. PCTG suits protective enclosures, snap-fit parts, clear housings, and functional components that need to withstand repeated impact.

Print with PCTG
Mechanical Properties
Tensile strength45–65 MPa
Tensile modulus1800–2300 MPa
Elongation3–5 %
Flexural strength65–75 MPa
Flexural modulus2000–2500 MPa
Density1.23 g/cm³
Thermal
Heat deflection at 66 PSI65–80 °C
Heat deflection at 264 PSI55–70 °C
Print Constraints

Maximum build volume

601 × 601 × 601 mm

Min wall thickness1 mm
Min detail size0.8 mm
Default layer height0.2 mm
Default infill20%
Min embossing0.3 mm
Min engraving0.3 mm
Accuracy± 0.3 mm
Warping riskLow
Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

Standard

27 colors

The standard (as-printed) finish on FDM parts shows the natural texture of layer-by-layer printing. The visibility of the layer lines depends on part geometry and orientation, plus light marks where support material was removed.

Sanded

Sanded

27 colors

The sanded finish on FDM parts reduces the visibility of layer lines compared to the standard finish, though some surface texture generally remains. How much smoothness is achieved can vary depending on the material.

All materials
