For AI agents: Materialize has an MCP server at /api/mcp and a plain-text guide to using it at /llms.txt. Read /llms.txt first. It covers uploading a model, checking it will print, choosing a material, getting a quote and ordering.

Print
Material
Nylon-Like Resin

Nylon-Like Resin

Functional Resins
Impact resistantHigh detailDurableStrong

Nylon-like resin is a tough, flexible photopolymer engineered to resemble nylon's characteristic ductility, bending under stress rather than cracking, with noticeably higher elongation and impact resistance than standard resin. It occupies similar territory to tough resin, and is generally aimed at functional prototypes and mechanical parts that need to survive handling and moderate stress. It should be noted that resin is a fundamentally different chemistry from true nylon, and even nylon-like formulations tend to be more brittle and less impact-resistant than actual nylon printed via FDM or SLS. Real nylon remains the better choice for parts facing high loads, frequent impacts, or long-term wear. Nylon-like resin suits functional prototypes, snap-fit parts, and mechanical components where added flexibility and toughness matter more than fine surface detail.

Print with Nylon-Like Resin
Mechanical Properties
Tensile strength38–65 MPa
Tensile modulus1500–2600 MPa
Elongation15–40 %
Flexural strength60–95 MPa
Flexural modulus1500–2500 MPa
Density1.15 g/cm³
Thermal
Heat deflection at 66 PSI50–75 °C
Print Constraints

Maximum build volume

650 × 650 × 650 mm

Min wall thicknessMSLA 0.6 mm, SLA 0.6 mm, LCD 0.6 mm, DLP 0.6 mm, DLS 2.5 mm, cDLM 0.6 mm
Min detail sizeMSLA 0.25 mm, SLA 0.25 mm, LCD 0.25 mm, DLP 0.25 mm, cDLM 0.5 mm
Default layer height0.1 mm
Default infill100%
Min embossing0.3 mm
Min engraving0.3 mm
Accuracy± 0.2 mm
Warping riskLow
Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

Standard

3 colors

Resin parts have a smooth surface with fine layer lines that are typically not very noticeable. The surface has a natural, semi-matte texture rather than a glossy shine, and marks from support removal can still be visible.

All materials
