Material
Nickel-Titanium (NiTi)

Nickel-Titanium (NiTi)

Alloys
StrongBiomedicalDurableCorrosion resistant

Nickel-Titanium (NiTi) alloy, commonly known as Nitinol, is a highly versatile shape memory alloy with a near-equiatomic composition of nickel and titanium. It is renowned for its unique properties, including shape memory, superelasticity, high fatigue resistance, and biocompatibility. The material undergoes reversible phase transformations, allowing it to recover its original shape after deformation when exposed to specific temperature changes. These characteristics make NiTi ideal for applications requiring flexibility and precision, such as medical implants, actuators, and components in aerospace and robotics. Additionally, NiTi exhibits corrosion resistance and excellent mechanical performance, further enhancing its suitability for demanding environments. Its behavior can be fine-tuned by adjusting composition and thermal treatment, offering adaptability across various industries.

Print with Nickel-Titanium (NiTi)
Mechanical Properties
Tensile strength700–1200 MPa
Tensile modulus28000–80000 MPa
Elongation8–25 %
Flexural modulus30000–80000 MPa
Density6.45 g/cm³
Print Constraints

Maximum build volume

250 × 250 × 300 mm

Default layer height0.05 mm
Default infill100%
Min embossing1 mm
Min engraving1 mm
Accuracy± 0.2 mm
Warping riskHigh
Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

Standard

1 color

Solid NiTi with a raw matte surface.

Sandblasted

Sandblasted

1 color

Solid NiTi with a matte slightly granular finish.
