High-Temperature Resin

Functional Resins

Heat resistantHigh detailDurableVisual

High-temperature resin offers a heat deflection temperature (HDT) of 99-142 °C at 0.45 MPa, the highest among all resins. It can be used to print detailed, precise prototypes with good temperature resistance.

Print with High-Temperature Resin

Mechanical Properties

Tensile strength42.2–81 MPa

Tensile modulus2450–4000 MPa

Elongation2.5–3.3 %

Flexural strength140 MPa

Flexural modulus2620–4260 MPa

Density1.3 g/cm³

Thermal

Heat deflection at 66 PSI99–142 °C

Print Constraints

Maximum build volume

800 × 800 × 550 mm

Default layer height0.1 mm

Default infill100%

Min embossing0.5 mm

Min engraving0.5 mm

Accuracy± 0.2 mm

Warping riskOver_140_mm

Interlocking partsNot supported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard Smooth

10 colors

UV-cured high temperature resin offers a HDT of 99-142 °C @ 0.45 MPa and a smooth surface.
