Carbon Fiber PETG

Composites

Wear resistantChemical resistantStrongDurable

Carbon-reinforced PETG contains short carbon fibers, which make the material even stiffer and stronger than normal PETG.

Print with Carbon Fiber PETG

Mechanical Properties

Tensile strength35–58 MPa

Tensile modulus2460–4900 MPa

Elongation3–10 %

Flexural strength70–82 MPa

Flexural modulus2910–5790 MPa

Density1.08 g/cm³

Thermal

Heat deflection at 66 PSI70–94 °C

Heat deflection at 264 PSI80–90 °C

Print Constraints

Maximum build volume

750 × 780 × 950 mm

Default layer height0.2 mm

Default infill20%

Min embossing0.4 mm

Min engraving0.4 mm

Accuracy± 0.4 mm

Warping riskModerate

Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

9 colors

Standard layered finish in various colors.

Sanded

9 colors

Smooth sanded finish.
