BioMed Resin

Functional Resins

FunctionalBiomedicalHigh detail

BioMed resin is a rigid material for biocompatible applications requiring short-term skin or mucosal membrane contact. Parts printed with BioMed resin are also compatible with common solvent disinfection and sterilization methods. It is designed to manufacture biocompatible 3D printed parts with high dimensional accuracy, stiffness, and strength.

Print with BioMed Resin

Mechanical Properties

Tensile strength52–73 MPa

Tensile modulus2080–3100 MPa

Elongation3–12.3 %

Flexural strength84–112 MPa

Flexural modulus2300–3300 MPa

Density1.2 g/cm³

Thermal

Heat deflection at 66 PSI67–119 °C

Heat deflection at 264 PSI54–94 °C

Print Constraints

Maximum build volume

345 × 190 × 345 mm

Default layer height0.05 mm

Default infill100%

Min embossing0.1 mm

Min engraving0.4 mm

Accuracy± 0.4 mm

Warping riskModerate

Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

4 colors

BioMed Resin is smooth and allows a high level of detail.
